Collaboration ​

Everyone who opens a saved dataflow while signed in shares one copy of it, which the Curio server keeps. The owner and the editors the owner invites change it together: code shows in everyone's editor as it is typed, and nodes, connections, widgets and scenarios change on every screen at once. Anyone else with the dataflow's link watches, read-only. An agent at work on the dataflow is one more person there.

Clip to recordtour:collaboration
Seen from the owner's screen: an invited editor joins and gets a chip in the dock, their cursor moves over the canvas, and the code they type shows in the node as they type it.

Invite editors ​

The owner of a saved dataflow invites editors by their username:

  1. On the canvas, choose Share > Invite editors.
  2. Type the account's Username and click Add. The account joins the Editors list, where the ✕ beside it removes it.
  3. Send them the dataflow's link, from Share > Copy dataflow link.

An editor opens the link and edits the dataflow with you. Adding or removing an editor counts at once, also for someone who has the dataflow open. Only an account can be an editor: a guest is never one, and a guest invites nobody.

WhoWhat they do
The ownerEdits, invites and removes editors, and works with the dataflow's agents.
An editorEdits code, nodes, connections, widgets and scenarios, runs the dataflow on the server, works with its agents, and asks the owner to add datasets, collections, packages and models of their own.
Anyone else with the linkWatches, read-only: every edit, keystroke and cursor shows as it lands, and their own cursor shows to the others. File > Save dataflow saves them a copy in their own projects.

A guest on a hosted Curio watches other accounts' dataflows. What it changes in an example, by hand or through its agents, goes to a copy of its own that no one else sees, until it signs out or the server restarts.

See who is here ​

The dock at the top of the canvas, beside the canvas agents, has a chip for each other person in the dataflow, with their initials in their color. Hover a chip for their name, their role and the node they are editing, such as Ana (editor), editing Street trees, and click it to move your view to where they point on the canvas. The Activity button at the end of the row lists who joined, who left and whose role changed.

Each person's pointer shows on the others' canvases as a cursor in their color with their name, at the same point of the dataflow whatever each of you has panned or zoomed to. A cursor that rests for 5 seconds fades until it moves again. A person's color comes from their account, so it is the same in each of their tabs. A node someone is in shows their initials in its corner; hover them to read Editing: and their name.

Edit together ​

  • Code and specs: each keystroke shows in the others' editors as it is typed, with each person's cursor in their color and their name over it, and it is kept as it is made. Ctrl+Z (Cmd+Z on a Mac) in a node's editor undoes your own typing in that node, never someone else's.
  • Everything else: adding, removing and connecting nodes, a widget's value, a scenario or a scenario set, and a node's title, size, chip size and settings change on every screen at once. While someone drags a node, the others see it move.
  • Runs are each person's own: a node's result shows on the canvas of whoever ran it. An editor's runs go to the server, as the owner's do, with the datasets, packages and models the owner added to the dataflow and the editor's own saved keys. The dataflow's saved outputs come from the owner's runs, and a watcher's runs stay in their tab.
  • An editor's own data reaches the dataflow through the owner's review. A file an editor drops on the canvas or on a node goes into the editor's own Data Catalog, and that drop, the editor's Add to project or a card of their Data Catalog dragged onto the canvas or a node asks the owner to add the dataset. Until the owner reviews it, the node reads WAITING on its dataset pill. The owner's Data Catalog drawer lists each request under Waiting for review, with Asked by and the editor's name: Apply copies the dataset into the owner's Data Catalog and adds it to the dataflow, and Dismiss leaves nothing behind. A collection of the editor's asks the same way, and its files come with it. A dataset of the shared catalog asks nothing.
  • An editor's own packages and models reach the dataflow through the owner's review too. The editor's Add to project in the Node Catalog or the Model Catalog, Import package, a card of either dropped on the canvas, and a model dropped on a node each ask the owner. The node is made at once, and its PACKAGE pill reads WAITING; on the owner's canvas it says who asks, with Review. The owner's Node Catalog or Model Catalog drawer lists the request under Waiting for review, with the package's name, version, publisher and the permissions it asks for. Apply opens the review the owner's own Add to project opens, then installs the package under the owner's account and adds it to the dataflow, after which the editor's runs use the owner's copy. A package whose files changed since it was installed, or whose libraries conflict with the owner's, is refused, and its card says why. A package or model of the shared catalog asks too, since a package runs only for an account that added it.

When two people change the same thing:

What happensWhat you see
You remove a node someone is typing inCurio asks first: Ana is editing this node. Remove it anyway?
Someone removes a node while you type in itA message names who removed it, with Put it back, which adds the node again with your code and the connections whose other end is still there.
You connect to a node someone removes at the same momentThe connection is not kept, and a message names who removed the node.
Two people set one widget, or drag one nodeEvery tab ends on the same value, or the same place.

Every change is kept ​

The server keeps each change as it is made, whoever makes it, and a tab that opens the dataflow later finds every change. On the owner's tab, the top bar reads Saved once the server has every change made there, Saving... while some are on their way, and Offline while Curio cannot reach the server. Leaving the dataflow, or closing its tab, asks first only while a change of yours has not reached the server.

File > Save dataflow, on the owner's tab, also saves the outputs the dataflow keeps, and is a version in the dataflow's history. An editor or a watcher saves a copy with File > Save dataflow, in their own projects.

The history is the same for the owner and the editors, in the Provenance drawer: a version for each node or connection added or removed, for each person's typing once they pause or leave the editor (Ana edited), for each change an agent makes (Node Builder, asked by Ana), and for each save and each version put back. Putting a version back changes everyone's canvas. A watcher sees no history, and only the owner can clear the history before a version.

Agents in the dataflow ​

An agent at work is one more person in the dataflow, from the moment a chat message, another agent, Solve or Build & validate starts it until its reply ends.

  • Its chip: every tab's dock has a chip for it, with its glyph in its category's color and a dot while it works. Hover it for who asked it, the nodes it is writing and the skills it is using, such as Node Builder (asked by Ana), editing Map Editor, using map-edits. A click opens its chat for the owner and the editors, and moves a watcher's view to the node it is writing. Activity says when it joined and who asked it, and what it did as it left: Dataflow Builder left: added 3 nodes and 2 connections.
  • Its cursor, for drags on the canvas only: when an agent adds a node, from its tile in the tool rail or a card in a catalog drawer, moves a node, or drops a card onto a node, every tab plays the drag. Its cursor, with its name, carries what it drags from where that tab shows it, and the change lands as the drop ends. A node's code, its settings, connections and removals land with no cursor.
  • The code in view: before an agent writes a node, it waits while someone else is in the node; after 30 seconds it gives up, and nothing changes. While it writes, it holds the node, whose corner shows the agent's glyph (Editing: Node Builder (asked by Ana)), and every tab showing the node turns it to its code or spec, or to its Widgets tab for a widget's value, and marks the changed lines or widgets for a moment. Then the node goes back to the tab it showed, unless you picked one meanwhile.
  • One action at a time: an agent's actions land in order. A Dataflow Builder plan is checked whole, then its nodes are dragged in one after another, with no code yet, and its connections and scenarios follow once the nodes they join are there. Clicking Build & validate plan, in the plan's strip, then writes their code one node at a time, in plan order. When someone removes a node the plan joins while it lands, the plan stops there: what landed stays, and its card in the chat says what was left undone.
  • Its changes: a node's code or settings, a new node or a plan land at once for everyone, as an edit does. Each is a version in the history named after the agent and who asked it, and its card in the chat has Undo (see AI agents).

The owner and the editors work with the dataflow's agents in chats they share, where a message someone else wrote shows their name above it. A reply shows in each of their tabs as it is written, and goes on when the tab that asked for it closes. A chat answers one message at a time: a message sent meanwhile waits its turn, whoever sent it can withdraw it, and the owner or any editor can stop a reply (see AI agents). An editor's chats answer with the owner's model and key, and name only the editor's own saved keys. An install an agent asks for in an editor's chat, such as a package, a dataset or a download from the Discovery Catalog, waits for the owner, who reviews it in the same chat. A watcher sees an agent at work in the dock and on the canvas, but not its badges or its chats.

On your own server ​

Inviting editors needs an account for each person, so a Curio you host for a group starts with --deploy (see Run your own server). On a Curio started without --deploy, everyone who opens it is its one local user, which owns every dataflow there: every tab edits, and each other tab shows as Shared Guest with a number, such as Shared Guest 2.

Collaboration travels over WebSocket connections at the backend's address plus /socket.io. Caddy's reverse_proxy passes them as they are; another reverse proxy must forward the Upgrade and Connection headers on that path. --collab-origins limits which origins' pages may connect, and a server people reach across a network you do not trust belongs behind HTTPS. Run one backend process: it keeps each open dataflow's live copy in its memory. Who is here, the locks and the Activity list are kept in that memory too, so a restart clears them.
